Products
Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:12V / 24V
Weight:198grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0922512XXLN | - | - | - | 12 | 2200 | 0.15 | 1.8 | 37.53 | 2.66 | 32.9 |
| DF0922512XXMN | - | - | - | 12 | 2500 | 0.25 | 3 | 41.61 | 2.82 | 33.6 |
| DF0922512XXHN | - | - | - | 12 | 3000 | 0.35 | 4.2 | 52.91 | 4.7 | 40.4 |
| DF0922512XXUN | - | - | - | 12 | 4200 | 0.6 | 7.2 | 79.86 | 7.7 | 43.2 |
| DF0922524XXLN | - | - | - | 24 | 2200 | 0.1 | 2.4 | 37.53 | 2.66 | 27.8 |
| DF0922524XXMN | - | - | - | 24 | 2500 | 0.12 | 2.88 | 41.61 | 2.82 | 30.5 |
| DF0922524XXHN | - | - | - | 24 | 3000 | 0.2 | 4.8 | 52.91 | 4.7 | 34.3 |
| DF0922524XXUN | - | - | - | 24 | 4200 | 0.43 | 10.32 | 79.86 | 7.7 | 43.2 |
