Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:12V / 24V
Weight:400grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF01203812XXLN | - | - | - | 12 | 2000 | 0.45 | 5.4 | 92.09 | 5.12 | 44.4 |
| DF01203812XXMN | - | - | - | 12 | 2300 | 0.63 | 7.56 | 107.6 | 7.05 | 46.1 |
| DF01203812XXHN | - | - | - | 12 | 2600 | 0.74 | 8.88 | 119.75 | 8.45 | 48.8 |
| DF01203812XXUN | - | - | - | 12 | 2900 | 1.28 | 15.36 | 132.46 | 10.39 | 51.3 |
| DF01203824XXLN | - | - | - | 24 | 2000 | 0.25 | 6 | 92.09 | 5.12 | 44.4 |
| DF01203824XXHN | - | - | - | 24 | 2300 | 0.31 | 7.44 | 107.6 | 7.05 | 46.1 |
| DF01203824XXMN | - | - | - | 24 | 2600 | 0.44 | 10.56 | 119.75 | 8.45 | 48.8 |
| DF01203824XXUN | - | - | - | 24 | 2900 | 0.6 | 14.4 | 132.46 | 10.39 | 51.3 |
| DF01203848XXLN | - | - | - | 48 | 2000 | 0.16 | 7.68 | 92.09 | 5.12 | 44.4 |
| DF01203848XXHN | - | - | - | 48 | 2300 | 0.18 | 8.64 | 107.6 | 7.05 | 46.1 |
| DF01203848XXMN | - | - | - | 48 | 2600 | 0.24 | 11.52 | 119.75 | 8.45 | 48.8 |
| DF01203848XXUN | - | - | - | 48 | 2900 | 0.3 | 14.4 | 132.46 | 10.39 | 51.3 |
