Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:5V / 12V
Weight:30grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0702512XXLN | - | - | - | 12 | 3000 | 0.18 | 2.2 | 26.4 | 4.4 | 38.5 |
| DF0702512XXMN | - | - | - | 12 | 3600 | 0.23 | 2.8 | 33.8 | 6.2 | 43.1 |
| DF0702512XXHN | - | - | - | 12 | 4000 | 0.25 | 3 | 36.63 | 7.62 | 45.3 |
| DF0702524XXLN | - | - | - | 24 | 3000 | 0.1 | 2.4 | 26.4 | 4.4 | 38.5 |
| DF0702524XXMN | - | - | - | 24 | 3600 | 0.13 | 3.12 | 33.8 | 6.2 | 43.1 |
| DF0702524XXHN | - | - | - | 24 | 4000 | 0.16 | 3.84 | 36.63 | 7.62 | 45.3 |
