Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:12V / 24V
Weight:77grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0701512XXLN | - | - | - | 12 | 3300 | 0.18 | 2.2 | 25.4 | 2.6 | 30.4 |
| DF0701512XXMN | - | - | - | 12 | 4300 | 0.29 | 3.5 | 34.4 | 5.2 | 35.4 |
| DF0701512XXHN | - | - | - | 12 | 4800 | 0.33 | 4 | 37.8 | 5.8 | 41.5 |
| DF0701524XXLN | - | - | - | 24 | 3300 | 0.12 | 2.9 | 25.4 | 2.6 | 30.4 |
| DF0701524XXMN | - | - | - | 24 | 4300 | 0.17 | 4.1 | 34.4 | 5.2 | 35.4 |
| DF0701524XXHN | - | - | - | 24 | 4800 | 0.23 | 5.5 | 37.8 | 5.8 | 41.5 |
