Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:12V / 24V
Weight:105grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0603812XXLN | - | - | - | 12 | 5000 | 0.27 | 3.2 | 32.2 | 8.4 | 42 |
| DF0603812XXMN | - | - | - | 12 | 6000 | 0.43 | 5.2 | 38.3 | 11.7 | 47 |
| DF0603812XXHN | - | - | - | 12 | 7000 | 0.6 | 7.2 | 44.8 | 15.5 | 52 |
| DF0603812XXUN | - | - | - | 12 | 8000 | 0.83 | 10 | 52.8 | 21.3 | 55 |
| DF0603824XXLN | - | - | - | 24 | 5000 | 0.15 | 3.6 | 32.2 | 8.4 | 42 |
| DF0603824XXMN | - | - | - | 24 | 6000 | 0.25 | 6 | 38.3 | 11.7 | 47 |
| DF0603824XXHN | - | - | - | 24 | 7000 | 0.3 | 7.2 | 44.8 | 15.5 | 52 |
| DF0603824XXUN | - | - | - | 24 | 8000 | 0.52 | 12.5 | 52.8 | 21.3 | 55 |
