Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:12V / 24V
Weight:51grams
Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
DF0602012XXLN | - | - | - | 12 | 4000 | 0.16 | 1.9 | 17 | 3.6 | 28 |
DF0602012XXMN | - | - | - | 12 | 4500 | 0.22 | 2.6 | 19 | 4.9 | 31 |
DF0602012XXHN | - | - | - | 12 | 5000 | 0.25 | 3 | 20 | 5.3 | 35 |
DF0602024XXLN | - | - | - | 24 | 4000 | 0.09 | 2.2 | 17 | 3.6 | 28 |
DF0602024XXMN | - | - | - | 24 | 4500 | 0.12 | 2.9 | 19 | 4.9 | 31 |
DF0602024XXHN | - | - | - | 24 | 5000 | 0.14 | 3.4 | 20 | 5.3 | 35 |
