Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:5V / 12V 24V
Weight:35grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0601505XXLN | - | - | - | 5 | 3000 | 0.16 | 0.8 | 14.8 | 1.8 | 26 |
| DF0601505XXMN | - | - | - | 5 | 3500 | 0.23 | 1.2 | 15.4 | 2.3 | 31 |
| DF0601512XXLN | - | - | - | 12 | 3000 | 0.1 | 1.2 | 14.8 | 1.8 | 26 |
| DF0601512XXMN | - | - | - | 12 | 3500 | 0.12 | 1.4 | 15.4 | 2.3 | 31 |
| DF0601512XXHN | - | - | - | 12 | 4000 | 0.16 | 1.9 | 18.7 | 3.8 | 33 |
| DF0601512XXUN | - | - | - | 12 | 4500 | 0.2 | 2.4 | 20.3 | 4.4 | 35 |
| DF0601524XXLN | - | - | - | 24 | 3000 | 0.08 | 1.9 | 14.8 | 1.8 | 26 |
| DF0601524XXMN | - | - | - | 24 | 3500 | 0.09 | 2.2 | 15.4 | 2.3 | 31 |
| DF0601524XXHN | - | - | - | 24 | 4000 | 0.11 | 2.6 | 18.7 | 3.8 | 33 |
| DF0601524XXUN | - | - | - | 24 | 4500 | 0.15 | 3.6 | 20.3 | 4.4 | 35 |
