Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:12V / 24V
Weight:20grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0402812XXLN | - | - | - | 12 | 8500 | 0.16 | 1.9 | 14.2 | 10.1 | 38 |
| DF0402812XXMN | - | - | - | 12 | 9500 | 0.22 | 2.2 | 16.8 | 11.8 | 45 |
| DF0402812XXHN | - | - | - | 12 | 10500 | 0.25 | 3 | 17.5 | 14.6 | 47 |
| DF0402812XXUN | - | - | - | 12 | 13000 | 0.39 | 4.7 | 23.5 | 22.5 | 48 |
| DF0402824XXLN | - | - | - | 24 | 8500 | 0.1 | 2.4 | 14.2 | 10.1 | 38 |
| DF0402824XXMN | - | - | - | 24 | 9500 | 0.12 | 2.9 | 16.8 | 11.8 | 45 |
| DF0402824XXHN | - | - | - | 24 | 10500 | 0.14 | 3.4 | 17.5 | 14.6 | 47 |
| DF0402824XXUN | - | - | - | 24 | 13000 | 0.23 | 5.5 | 23.5 | 22.5 | 48 |
