Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:5V / 12V / 24V
Weight:16grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0401005XXLN | - | - | - | 5 | 4500 | 0.12 | 0.6 | 4.5 | 1.49 | 23.85 |
| DF0401005XXMN | - | - | - | 5 | 5500 | 0.14 | 0.7 | 5.1 | 2.49 | 29.15 |
| DF0401005XXHN | - | - | - | 5 | 6500 | 0.18 | 0.9 | 6.8 | 4.04 | 34.45 |
| DF0401012XXLN | - | - | - | 12 | 4500 | 0.07 | 0.7 | 4.5 | 1.49 | 23.85 |
| DF0401012XXMN | - | - | - | 12 | 5500 | 0.08 | 1 | 5.1 | 2.49 | 29.15 |
| DF0401012XXHN | - | - | - | 12 | 6500 | 0.1 | 1.2 | 6.8 | 4.04 | 34.45 |
| DF0401012XXUN | - | - | - | 12 | 7500 | 0.12 | 1.4 | 7.5 | 4.39 | 39.75 |
| DF0401024XXLN | - | - | - | 24 | 4500 | 0.05 | 1.2 | 4.5 | 1.49 | 23.85 |
| DF0401024XXMN | - | - | - | 24 | 5500 | 0.06 | 1.4 | 5.1 | 2.49 | 29.15 |
| DF0401024XXHN | - | - | - | 24 | 6500 | 0.07 | 1.7 | 6.8 | 4.04 | 34.45 |
| DF0401024XXUN | - | - | - | 24 | 7500 | 0.08 | 1.9 | 7.5 | 4.39 | 39.75 |
