Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:5V / 12V
Weight:5grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0300605XXLN | - | - | - | 5 | 5800 | 0.09 | 0.45 | 1.43 | 0.83 | 19 |
| DF0300605XXMN | - | - | - | 5 | 6800 | 0.11 | 0.55 | 2.32 | 1.8 | 20 |
| DF0300605XXHN | - | - | - | 5 | 7800 | 0.12 | 0.6 | 3.1 | 2.7 | 21 |
| DF0300612XXLN | - | - | - | 12 | 5800 | 0.06 | 0.7 | 1.43 | 0.83 | 19 |
| DF0300612XXMN | - | - | - | 12 | 6800 | 0.07 | 0.8 | 2.32 | 1.8 | 20 |
| DF0300612XXHN | - | - | - | 12 | 7800 | 0.08 | 1 | 3.1 | 2.7 | 21 |
