Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:12V / 24V
Weight:126grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF01202512XXLN | - | - | - | 12 | 1800 | 0.3 | 3.6 | 69.85 | 1.33 | 35.1 |
| DF01202512XXMN | - | - | - | 12 | 2200 | 0.42 | 5.04 | 88 | 3.82 | 42.4 |
| DF01202512XXHN | - | - | - | 12 | 2600 | 0.9 | 10.8 | 98.64 | 5.07 | 44.9 |
| DF01202524XXLN | - | - | - | 24 | 1800 | 0.18 | 4.32 | 69.85 | 1.33 | 3.51 |
| DF01202524XXMN | - | - | - | 24 | 2200 | 0.28 | 6.72 | 88 | 3.82 | 42.4 |
| DF01202524XXHN | - | - | - | 24 | 2600 | 0.5 | 12 | 98.64 | 5.07 | 44.9 |
