Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:12V / 24V
Weight:160grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0973312XXLN | - | - | - | 12 | 2200 | 0.22 | 2.6 | 16.4 | 6.6 | 41 |
| DF0973312XXMN | - | - | - | 12 | 2700 | 0.34 | 4.1 | 20.1 | 11.4 | 46 |
| DF0973312XXHN | - | - | - | 12 | 3200 | 0.75 | 9 | 24.4 | 16.3 | 50 |
| DF0973312XXUN | - | - | - | 12 | 3400 | 0.85 | 10.2 | 26.4 | 18.5 | 52 |
| DF0973324XXLN | - | - | - | 24 | 2200 | 0.1 | 2.4 | 16.4 | 6.6 | 41 |
| DF0973324XXMN | - | - | - | 24 | 2700 | 0.16 | 3.8 | 20.1 | 11.4 | 46 |
| DF0973324XXHN | - | - | - | 24 | 3200 | 0.26 | 6.2 | 24.4 | 16.3 | 50 |
| DF0973324XXUN | - | - | - | 24 | 3400 | 0.4 | 9.6 | 26.4 | 18.5 | 52 |
