Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:5V / 12V
Weight:38grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0511505XXLN | - | - | - | 5 | 4000 | 0.2 | 1 | 2.53 | 4.4 | 30.4 |
| DF0511505XXMN | - | - | - | 5 | 5000 | 0.33 | 1.65 | 3.77 | 8.74 | 35.4 |
| DF0511505XXHN | - | - | - | 5 | 6000 | 0.65 | 3.25 | 4.02 | 12.69 | 40.5 |
| DF0511512XXLN | - | - | - | 12 | 4000 | 0.14 | 1.68 | 2.53 | 4.4 | 30.4 |
| DF0511512XXMN | - | - | - | 12 | 5000 | 0.15 | 1.8 | 3.77 | 8.74 | 35.4 |
| DF0511512XXHN | - | - | - | 12 | 6000 | 0.31 | 3.72 | 4.02 | 12.69 | 40.5 |
| DF0511512XXUN | - | - | - | 12 | 4800 | 0.19 | 2.3 | 18.6 | 3.8 | 37.5 |
