Description
Frame Type:Plastic housing and blade material are UL 94V-0 rating
Impeller:Plastic(UL:94-0)
Bearing:Ball / 1Ball / Sleeve Bearing
Operating Temperature:-10°C to +70°C
Lead Wire:UL 1007 AWG#26
Voltage Available:5V / 12V
Weight:42grams
Specification
| Model | Bearing SE | Bearing B1 | Bearing B2 | Voltage (v) | Speed (RPM) | Current (A) | Power (W) | AirFlow (CFM) | StaticPressure (mm-Aq) | Noise dB(A) |
| DF0502505XXLN | - | - | - | 5 | 4000 | 0.31 | 1.55 | 3.96 | 7.65 | 34.3 |
| DF0502505XXMN | - | - | - | 5 | 4500 | 0.49 | 2.45 | 5.29 | 10.2 | 37.7 |
| DF0502505XXHN | - | - | - | 5 | 5000 | 0.69 | 3.45 | 6.5 | 12.69 | 38.5 |
| DF0502512XXLN | - | - | - | 12 | 4000 | 0.18 | 2.16 | 3.96 | 7.65 | 34.3 |
| DF0502512XXMN | - | - | - | 12 | 4500 | 0.21 | 2.52 | 5.29 | 10.2 | 37.7 |
| DF0502512XXHN | - | - | - | 12 | 5000 | 0.34 | 4.08 | 6.5 | 12.69 | 38.5 |
