产品
描述
框架类型：Plastic housing and blade material are UL 94V-0 rating
叶轮：Plastic(UL:94-0)
轴承：Ball / 1Ball / Sleeve Bearing
工作温度：-10°C to +70°C
导线：UL 1007 AWG#26
可用电压：12V / 24V / 48V
重量：80g
规格
| 机种 | 轴承 SE | 轴承 B1 | 轴承 B2 | 额定 电压(v) | 转速 (RPM) | 额定 电流(A) | 功率 (W) | 风量 (CFM) | 静压 (mm-Aq) | 噪音 dB(A) |
| DF0922512XXLN | - | - | - | 12 | 2200 | 0.15 | 1.8 | 37.53 | 2.66 | 32.9 |
| DF0922512XXMN | - | - | - | 12 | 2500 | 0.25 | 3 | 41.61 | 2.82 | 33.6 |
| DF0922512XXHN | - | - | - | 12 | 3000 | 0.35 | 4.2 | 52.91 | 4.7 | 40.4 |
| DF0922512XXUN | - | - | - | 12 | 4200 | 0.9 | 10.8 | 79.86 | 7.7 | 49.2 |
| DF0922524XXLN | - | - | - | 24 | 2200 | 0.1 | 2.4 | 37.53 | 2.66 | 32.9 |
| DF0922524XXMN | - | - | - | 24 | 2500 | 0.12 | 2.88 | 41.61 | 2.82 | 33.6 |
| DF0922524XXHN | - | - | - | 24 | 3000 | 0.21 | 5.04 | 52.91 | 4.7 | 40.4 |
| DF0922524XXUN | - | - | - | 24 | 4200 | 0.44 | 10.56 | 79.86 | 7.7 | 49.2 |
| DF0922548XXLN | - | - | - | 48 | 2200 | 0.08 | 3.84 | 37.53 | 2.66 | 32.9 |
| DF0922548XXMN | - | - | - | 48 | 2500 | 0.1 | 4.8 | 41.61 | 2.82 | 33.6 |
| DF0922548XXHN | - | - | - | 48 | 3000 | 0.15 | 7.2 | 52.91 | 4.7 | 40.4 |
| DF0922548XXUN | - | - | - | 48 | 4200 | 0.4 | 19.2 | 79.86 | 7.7 | 49.2 |
