产品
描述
框架类型：Plastic housing and blade material are UL 94V-0 rating
叶轮：Plastic(UL:94-0)
轴承：Ball / 1Ball / Sleeve Bearing
工作温度：-10°C to +70°C
导线：UL 1007 AWG#26
可用电压：12V / 24V
重量：260g
规格
| 机种 | 轴承 SE | 轴承 B1 | 轴承 B2 | 额定 电压(v) | 转速 (RPM) | 额定 电流(A) | 功率 (W) | 风量 (CFM) | 静压 (mm-Aq) | 噪音 dB(A) |
| DF01203212XXLN | - | - | - | 12 | 2200 | 0.23 | 2.76 | 20.97 | 7.62 | 49.2 |
| DF01203212XXMN | - | - | - | 12 | 2600 | 0.28 | 3.36 | 23.77 | 10.16 | 53.6 |
| DF01203212XXHN | - | - | - | 12 | 3200 | 0.52 | 6.24 | 30.56 | 15.24 | 56.1 |
| DF01203212XXUN | - | - | - | 12 | 3600 | 0.71 | 8.52 | 33.88 | 19.812 | 58.6 |
| DF01203224XXLN | - | - | - | 24 | 2200 | 0.13 | 3.12 | 20.97 | 7.62 | 49.2 |
| DF01203224XXHN | - | - | - | 24 | 2600 | 0.19 | 4.56 | 23.77 | 10.16 | 53.6 |
| DF01203224XXMN | - | - | - | 24 | 3200 | 0.34 | 8.16 | 30.56 | 15.24 | 56.1 |
| DF01203224XXUN | - | - | - | 24 | 3600 | 0.47 | 11.28 | 33.88 | 19.81 | 58.6 |
