产品
描述
框架类型：Plastic housing and blade material are UL 94V-0 rating
叶轮：Plastic(UL:94-0)
轴承：Ball / 1Ball / Sleeve Bearing
工作温度：-10°C to +70°C
导线：UL 1007 AWG#26
可用电压：12V / 24V
重量：160g
规格
| 机种 | 轴承 SE | 轴承 B1 | 轴承 B2 | 额定 电压(v) | 转速 (RPM) | 额定 电流(A) | 功率 (W) | 风量 (CFM) | 静压 (mm-Aq) | 噪音 dB(A) |
| DF0973312XXLN | - | - | - | 12 | 2200 | 0.22 | 2.6 | 16.4 | 6.6 | 41 |
| DF0973312XXMN | - | - | - | 12 | 2700 | 0.34 | 4.1 | 20.1 | 11.4 | 46 |
| DF0973312XXHN | - | - | - | 12 | 3200 | 0.75 | 9 | 24.4 | 16.3 | 50 |
| DF0973312XXUN | - | - | - | 12 | 3400 | 0.85 | 10.2 | 26.4 | 18.5 | 52 |
| DF0973324XXLN | - | - | - | 24 | 2200 | 0.1 | 2.4 | 16.4 | 6.6 | 41 |
| DF0973324XXMN | - | - | - | 24 | 2700 | 0.16 | 3.8 | 20.1 | 11.4 | 46 |
| DF0973324XXHN | - | - | - | 24 | 3200 | 0.26 | 6.2 | 24.4 | 16.3 | 50 |
| DF0973324XXUN | - | - | - | 24 | 3400 | 0.4 | 9.6 | 26.4 | 18.5 | 52 |
