产品
描述
框架类型：Plastic housing and blade material are UL 94V-0 rating
叶轮：Plastic(UL:94-0)
轴承：Ball / 1Ball / Sleeve Bearing
工作温度：-10°C to +70°C
导线：UL 1007 AWG#26
可用电压：5V / 12V / 24V / 48V
重量：68g
规格
| 机种 | 轴承 SE | 轴承 B1 | 轴承 B2 | 额定 电压(v) | 转速 (RPM) | 额定 电流(A) | 功率 (W) | 风量 (CFM) | 静压 (mm-Aq) | 噪音 dB(A) |
| DF0802505XXLN | - | - | - | 05 | 2200 | 0.31 | 1.6 | 24.2 | 1.7 | 25.4 |
| DF0802505XXMN | - | - | - | 05 | 2500 | 0.42 | 2.1 | 29.4 | 2.8 | 31.8 |
| DF0802505XXHN | - | - | - | 05 | 3000 | 0.51 | 2.6 | 40.1 | 4.1 | 37.9 |
| DF0802512XXLN | - | - | - | 12 | 2200 | 0.1 | 1.2 | 24.2 | 1.7 | 25.4 |
| DF0802512XXMN | - | - | - | 12 | 2500 | 0.13 | 1.6 | 29.4 | 2.8 | 31.8 |
| DF0802512XXHN | - | - | - | 12 | 3000 | 0.2 | 2.4 | 40.1 | 4.1 | 37.9 |
| DF0802512XXUN | - | - | - | 12 | 4000 | 0.39 | 4.7 | 49.2 | 6.4 | 44.9 |
| DF0802524XXLN | - | - | - | 24 | 2200 | 0.08 | 1.9 | 24.2 | 1.7 | 25.4 |
| DF0802524XXMN | - | - | - | 24 | 2500 | 0.11 | 2.6 | 29.4 | 2.8 | 31.8 |
| DF0802524XXHN | - | - | - | 24 | 3000 | 0.14 | 3.4 | 40.1 | 4.1 | 37.9 |
| DF0802524XXUN | - | - | - | 24 | 4000 | 0.23 | 5.5 | 49.2 | 6.4 | 44.9 |
| DF0802548XXLN | - | - | - | 48 | 2200 | 0.04 | 1.9 | 24.2 | 1.7 | 25.4 |
| DF0802548XXMN | - | - | - | 48 | 2500 | 0.05 | 2.4 | 29.2 | 2.8 | 31.8 |
| DF0802548XXHN | - | - | - | 48 | 3000 | 0.07 | 3.4 | 40.1 | 4.1 | 37.9 |
| DF0802548XXUN | - | - | - | 48 | 4000 | 0.16 | 7.7 | 49.2 | 6.4 | 44.9 |
