产品
描述
框架类型：Plastic housing and blade material are UL 94V-0 rating
叶轮：Plastic(UL:94-0)
轴承：Ball / 1Ball / Sleeve Bearing
工作温度：-10°C to +70°C
导线：UL 1007 AWG#26
可用电压：12V / 24V / 48V
重量：56g
规格
| 机种 | 轴承 SE | 轴承 B1 | 轴承 B2 | 额定 电压(v) | 转速 (RPM) | 额定 电流(A) | 功率 (W) | 风量 (CFM) | 静压 (mm-Aq) | 噪音 dB(A) |
| DF0602512XXLN | - | - | - | 12 | 3300 | 0.12 | 1.4 | 15.06 | 3.1 | 27 |
| DF0602512XXMN | - | - | - | 12 | 3800 | 0.16 | 1.9 | 17.52 | 4.1 | 30 |
| DF0602512XXHN | - | - | - | 12 | 4500 | 0.18 | 2.2 | 21.38 | 5.8 | 32 |
| DF0602512XXUN | - | - | - | 12 | 5000 | 0.22 | 2.6 | 24.35 | 6.4 | 34 |
| DF0602524XXLN | - | - | - | 24 | 3300 | 0.09 | 2.2 | 15.06 | 3.1 | 27 |
| DF0602524XXMN | - | - | - | 24 | 3800 | 0.1 | 2.4 | 17.52 | 4.1 | 30 |
| DF0602524XXHN | - | - | - | 24 | 4500 | 0.12 | 2.9 | 21.38 | 5.8 | 32 |
| DF0602524XXUN | - | - | - | 24 | 5000 | 0.15 | 3.6 | 24.35 | 6.4 | 34 |
| DF0602548XXLN | - | - | - | 48 | 3300 | 0.06 | 2.9 | 15.06 | 3.1 | 27 |
| DF0602548XXMN | - | - | - | 48 | 3800 | 0.07 | 3.4 | 17.52 | 4.1 | 30 |
| DF0602548XXHN | - | - | - | 48 | 4500 | 0.08 | 3.8 | 21.38 | 5.8 | 32 |
| DF0602548XXUN | - | - | - | 48 | 5000 | 0.09 | 4.3 | 24.35 | 6.4 | 34 |
