产品
描述
框架类型：Plastic housing and blade material are UL 94V-0 rating
叶轮：Plastic(UL:94-0)
轴承：Ball / 1Ball / Sleeve Bearing
工作温度：-10°C to +70°C
导线：UL 1007 AWG#26
可用电压：5V / 12V
重量：30g
规格
| 机种 | 轴承 SE | 轴承 B1 | 轴承 B2 | 额定 电压(v) | 转速 (RPM) | 额定 电流(A) | 功率 (W) | 风量 (CFM) | 静压 (mm-Aq) | 噪音 dB(A) |
| DF0601005XXLN | - | - | - | 5 | 3000 | 0.14 | 0.7 | 11.1 | 1.5 | 27.6 |
| DF0601005XXMN | - | - | - | 5 | 3600 | 0.22 | 1.1 | 13.7 | 2.1 | 29.4 |
| DF0601012XXLN | - | - | - | 12 | 3000 | 0.1 | 1.2 | 11.1 | 1.5 | 27.6 |
| DF0601012XXMN | - | - | - | 12 | 3600 | 0.12 | 1.4 | 13.7 | 2.1 | 29.4 |
| DF0601012XXHN | - | - | - | 12 | 4200 | 0.15 | 1.8 | 16.4 | 3.1 | 33.6 |
| DF0601012XXUN | - | - | - | 12 | 4800 | 0.19 | 2.3 | 18.6 | 3.8 | 37.5 |
