产品
描述
框架类型：Plastic housing and blade material are UL 94V-0 rating
叶轮：Plastic(UL:94-0)
轴承：Ball / 1Ball / Sleeve Bearing
工作温度：-10°C to +70°C
导线：UL 1007 AWG#26
可用电压：5V / 12V
重量：16g
规格
| 机种 | 轴承 SE | 轴承 B1 | 轴承 B2 | 额定 电压(v) | 转速 (RPM) | 额定 电流(A) | 功率 (W) | 风量 (CFM) | 静压 (mm-Aq) | 噪音 dB(A) |
| DF0501005XXLN | - | - | - | 5 | 3500 | 0.12 | 0.6 | 6.28 | 1.3 | 26 |
| DF0501005XXMN | - | - | - | 5 | 4500 | 0.18 | 0.9 | 8.38 | 1.5 | 28 |
| DF0501005XXHN | - | - | - | 5 | 5300 | 0.22 | 1.1 | 10.68 | 3.2 | 30 |
| DF0501012XXLN | - | - | - | 12 | 3500 | 0.06 | 0.7 | 6.28 | 1.3 | 26 |
| DF0501012XXMN | - | - | - | 12 | 4500 | 0.08 | 1 | 8.38 | 1.5 | 28 |
| DF0501012XXHN | - | - | - | 12 | 5300 | 0.13 | 1.6 | 10.68 | 3.2 | 30 |
