产品
描述
框架类型：Plastic housing and blade material are UL 94V-0 rating
叶轮：Plastic(UL:94-0)
轴承：Ball / 1Ball / Sleeve Bearing
工作温度：-10°C to +70°C
导线：UL 1007 AWG#26
可用电压：5V / 12V
重量：5g
规格
| 机种 | 轴承 SE | 轴承 B1 | 轴承 B2 | 额定 电压(v) | 转速 (RPM) | 额定 电流(A) | 功率 (W) | 风量 (CFM) | 静压 (mm-Aq) | 噪音 dB(A) |
| DF0300605XXLN | - | - | - | 5 | 5800 | 0.09 | 0.45 | 1.43 | 0.83 | 19 |
| DF0300605XXMN | - | - | - | 5 | 6800 | 0.11 | 0.55 | 2.32 | 1.8 | 20 |
| DF0300605XXHN | - | - | - | 5 | 7800 | 0.12 | 0.6 | 3.1 | 2.7 | 21 |
| DF0300612XXLN | - | - | - | 12 | 5800 | 0.06 | 0.7 | 1.43 | 0.83 | 19 |
| DF0300612XXMN | - | - | - | 12 | 6800 | 0.07 | 0.8 | 2.32 | 1.8 | 20 |
| DF0300612XXHN | - | - | - | 12 | 7800 | 0.08 | 1 | 3.1 | 2.7 | 21 |
