产品
描述
框架类型：Plastic housing and blade material are UL 94V-0 rating
叶轮：Plastic(UL:94-0)
轴承：Ball / 1Ball / Sleeve Bearing
工作温度：-10°C to +70°C
导线：UL 1007 AWG#26
可用电压：5V / 12V
重量：16g
规格
| 机种 | 轴承 SE | 轴承 B1 | 轴承 B2 | 额定 电压(v) | 转速 (RPM) | 额定 电流(A) | 功率 (W) | 风量 (CFM) | 静压 (mm-Aq) | 噪音 dB(A) |
| DF0511505XXLN | - | - | - | 5 | 4000 | 0.2 | 1 | 2.53 | 4.4 | 30.4 |
| DF0511505XXMN | - | - | - | 5 | 5000 | 0.33 | 1.65 | 3.77 | 8.74 | 35.4 |
| DF0511505XXHN | - | - | - | 5 | 6000 | 0.65 | 3.25 | 4.02 | 12.69 | 40.5 |
| DF0511512XXLN | - | - | - | 12 | 4000 | 0.14 | 1.68 | 2.53 | 4.4 | 30.4 |
| DF0511512XXMN | - | - | - | 12 | 5000 | 0.15 | 1.8 | 3.77 | 8.74 | 35.4 |
| DF0511512XXHN | - | - | - | 12 | 6000 | 0.31 | 3.72 | 4.02 | 12.69 | 40.5 |
| DF0511512XXUN | - | - | - | 12 | 4800 | 0.19 | 2.3 | 18.6 | 3.8 | 37.5 |
