65 Channels USB Bluetooth GPS Receiver Data Logger

Stop production

Fast Acquisition high-Sensitivit
65 Channels + High sensitivity + 38400bps baud + Data Logger

2M Bytes flash memory for data logging, with 16 bytes binary data per record that stores up to 256,000 data records

The GT-750FL is capable of keeping up to 256,000 recordsor positions, including longitude, latitude, speed, UTC, and tag data. The location histories can be exported to mapping software such as Google Earth or TrackMaker.

FEATURES
• 65 channels "All-In-View" tracking
• Skytraq low power chipset simultaneous time-frequency search bins
• High sensitivity:-159dBm tracking
• Cold start time <29 sec.(Average)
• Warm start time <10 sec. (Average)
• Hot start time <1 sec. (Average) under open sky
• Support A-GPS function
• SBAS (WAAS, EGNOS) support
• 8M Bytes flash memory for data logging, with 16 bytes binary data per record that stores up to 1,000,000 data records
• Log data can be exported to mapping software suchas Google Earth and TrackMaker
• Logging data interval programmable:by time or distance
• 5m CEP accuracy
• Reacquisition sensitivity time:0.1sec.
• Support standard NMEA-0183 at 38400 bps baud rate
• Built in ceramic patch antenna
• Bluetooth version 2.0 compliant
• Compatible with Bluetooth devices with Serial Port Profile (SPP)
• Charger circuitry and battery socket for N3650 Li-ION battery (1000mAh)
• More than 13 hours of operation

The GT-750FL is a single board of Bluetooth GPS receiver for customers who require easy system integration and minimal development risk.

The GT-750FL is optimized for excellent performance and low cost. Its 65 parallel channels and Skytraq low power chipset search bins provide short start-up time and fast signal acquisition. Having fast time-to-first-fix and high sensitivity, the GT-750FL offers good navigation performance even in urban canyons.

Satellite-based augmentation systems, such as WAAS and EGNOS, are supported to yield improved accuracy.

The on board patch antenna provides good signal reception. It provides fast satellite signal acquisition and short startup time. Acquisition sensitivity of –155dBm and tracking sensitivity of –159dBm offers good navigation performance even in urban canyons having limited sky view.

Class 2 Bluetooth offers up to 10 meters of wireless operation with Bluetooth-enabled devices such as PDA / PAD
