產品
描述
框架類型：Plastic housing and blade material are UL 94V-0 rating
葉輪：Plastic(UL:94-0)
軸承：Ball / 1Ball / Sleeve Bearing
工作溫度：-10°C to +70°C
導線：UL 1007 AWG#26
可用電壓：12V / 24V
重量：198g
規格
| 機種 | 軸承 SE | 軸承 B1 | 軸承 B2 | 額定 電壓(v) | 轉速 (RPM) | 額定 電流(A) | 功率 (W) | 風量 (CFM) | 靜壓 (mm-Aq) | 噪音 dB(A) |
| DF0922512XXLN | - | - | - | 12 | 2200 | 0.15 | 1.8 | 37.53 | 2.66 | 32.9 |
| DF0922512XXMN | - | - | - | 12 | 2500 | 0.25 | 3 | 41.61 | 2.82 | 33.6 |
| DF0922512XXHN | - | - | - | 12 | 3000 | 0.35 | 4.2 | 52.91 | 4.7 | 40.4 |
| DF0922512XXUN | - | - | - | 12 | 4200 | 0.6 | 7.2 | 79.86 | 7.7 | 43.2 |
| DF0922524XXLN | - | - | - | 24 | 2200 | 0.1 | 2.4 | 37.53 | 2.66 | 27.8 |
| DF0922524XXMN | - | - | - | 24 | 2500 | 0.12 | 2.88 | 41.61 | 2.82 | 30.5 |
| DF0922524XXHN | - | - | - | 24 | 3000 | 0.2 | 4.8 | 52.91 | 4.7 | 34.3 |
| DF0922524XXUN | - | - | - | 24 | 4200 | 0.43 | 10.32 | 79.86 | 7.7 | 43.2 |
