產品
描述
框架類型：Plastic housing and blade material are UL 94V-0 rating
葉輪：Plastic(UL:94-0)
軸承：Ball / 1Ball / Sleeve Bearing
工作溫度：-10°C to +70°C
導線：UL 1007 AWG#26
可用電壓：5V / 12V / 24V
重量：26g
規格
| 機種 | 軸承 SE | 軸承 B1 | 軸承 B2 | 額定 電壓(v) | 轉速 (RPM) | 額定 電流(A) | 功率 (W) | 風量 (CFM) | 靜壓 (mm-Aq) | 噪音 dB(A) |
| DF0402005XXLN | - | - | - | 5 | 5500 | 0.12 | 0.6 | 6.64 | 3.9 | 23 |
| DF0402005XXMN | - | - | - | 5 | 6500 | 0.18 | 0.9 | 8.34 | 4.7 | 28 |
| DF0402005XXHN | - | - | - | 5 | 7500 | 0.22 | 1.1 | 9.63 | 6.6 | 30 |
| DF0402012XXLN | - | - | - | 12 | 5500 | 0.08 | 1 | 6.64 | 3.9 | 23 |
| DF0402012XXMN | - | - | - | 12 | 6500 | 0.1 | 1.2 | 8.34 | 4.7 | 28 |
| DF0402012XXHN | - | - | - | 12 | 7500 | 0.12 | 1.4 | 9.63 | 6.6 | 30 |
| DF0402012XXUN | - | - | - | 12 | 8500 | 0.16 | 1.9 | 10.86 | 9.1 | 34 |
| DF0402024XXLN | - | - | - | 24 | 5500 | 0.06 | 1.4 | 6.64 | 3.9 | 23 |
| DF0402024XXMN | - | - | - | 24 | 6500 | 0.07 | 1.7 | 8.34 | 4.7 | 28 |
| DF0402024XXHN | - | - | - | 24 | 7500 | 0.08 | 1.9 | 9.63 | 6.6 | 30 |
| DF0402024XXUN | - | - | - | 24 | 8500 | 0.09 | 2.2 | 10.86 | 9.1 | 34 |
