產品
描述
框架類型：Plastic housing and blade material are UL 94V-0 rating
葉輪：Plastic(UL:94-0)
軸承：Ball / 1Ball / Sleeve Bearing
工作溫度：-10°C to +70°C
導線：UL 1007 AWG#26
可用電壓：5V / 12V
重量：16g
規格
| 機種 | 軸承 SE | 軸承 B1 | 軸承 B2 | 額定 電壓(v) | 轉速 (RPM) | 額定 電流(A) | 功率 (W) | 風量 (CFM) | 靜壓 (mm-Aq) | 噪音 dB(A) |
| DF0511505XXLN | - | - | - | 5 | 4000 | 0.2 | 1 | 2.53 | 4.4 | 30.4 |
| DF0511505XXMN | - | - | - | 5 | 5000 | 0.33 | 1.65 | 3.77 | 8.74 | 35.4 |
| DF0511505XXHN | - | - | - | 5 | 6000 | 0.65 | 3.25 | 4.02 | 12.69 | 40.5 |
| DF0511512XXLN | - | - | - | 12 | 4000 | 0.14 | 1.68 | 2.53 | 4.4 | 30.4 |
| DF0511512XXMN | - | - | - | 12 | 5000 | 0.15 | 1.8 | 3.77 | 8.74 | 35.4 |
| DF0511512XXHN | - | - | - | 12 | 6000 | 0.31 | 3.72 | 4.02 | 12.69 | 40.5 |
| DF0511512XXUN | - | - | - | 12 | 4800 | 0.19 | 2.3 | 18.6 | 3.8 | 37.5 |
