產品
描述
框架類型：Plastic housing and blade material are UL 94V-0 rating
葉輪：Plastic(UL:94-0)
軸承：Ball / 1Ball / Sleeve Bearing
工作溫度：-10°C to +70°C
導線：UL 1007 AWG#26
可用電壓：5V / 12V
重量：42g
規格
| 機種 | 軸承 SE | 軸承 B1 | 軸承 B2 | 額定 電壓(v) | 轉速 (RPM) | 額定 電流(A) | 功率 (W) | 風量 (CFM) | 靜壓 (mm-Aq) | 噪音 dB(A) |
| DF0502505XXLN | - | - | - | 5 | 4000 | 0.31 | 1.55 | 3.96 | 7.65 | 34.3 |
| DF0502505XXMN | - | - | - | 5 | 4500 | 0.49 | 2.45 | 5.29 | 10.2 | 37.7 |
| DF0502505XXHN | - | - | - | 5 | 5000 | 0.69 | 3.45 | 6.5 | 12.69 | 38.5 |
| DF0502512XXLN | - | - | - | 12 | 4000 | 0.18 | 2.16 | 3.96 | 7.65 | 34.3 |
| DF0502512XXMN | - | - | - | 12 | 4500 | 0.21 | 2.52 | 5.29 | 10.2 | 37.7 |
| DF0502512XXHN | - | - | - | 12 | 5000 | 0.34 | 4.08 | 6.5 | 12.69 | 38.5 |
